Features
-
IPX4 Rating –
This tool has IPX4-rated weather-resistant construction and has been designed and tested for adverse weather conditions. -
STIHL Quickstop® Plus –
STIHL offers an additional, manually-activated chain brake on select models. This system is designed to engage when the operator’s right hand completely releases the rear handle, stopping the chain within one second. -
Ematic™ Lubrication System –
The Ematic™ guide bar, when used with STIHL OILOMATIC® saw chain, will provide proper lubrication and less oil consumption than conventional methods. The system works because two ramps, strategically placed in the guide bar rail, help contain the flow of oil and direct all lubrication to the sliding faces of the bar and chain links as well as the rivets and driver holes, which in turn can reduce bar oil consumption up to 50%. -
Quick Chain Adjuster (QCA) (B) –
The Quick Chain Adjuster (QCA) (B) allows the user to adjust the tension of the chain without the use of tools. This allows for easy chain adjustment. -
Lightweight Portability –
This product is lightweight for easy portability, great maneuverability, and extended use. -
Variable-Speed Trigger –
The variable-speed trigger allows precise control for each task. -
Rubberized Soft-Touch Handle –
Soft rubber texture is both easy to grip and makes the product comfortable to hold for extended periods. -
Toolless and Translucent Bar and Chain Oil Tank –
The translucent bar and chain oil tank makes it easy for users to check oil levels at a glance. -
Throttle Trigger Interlock –
This safety feature must be depressed before the trigger can be activated. -
Reduced-Emission Engine Technology—Caring for Nature –
The STIHL Inc. “Caring for Nature” seal identifies its powered products that are more environmentally conscious, producing zero or low exhaust emissions. STIHL Inc. defines “low exhaust emissions” as being cleaner than EPA and/or CARB exhaust emission standards.
-
-
Specifications
POWER SOURCE Battery POWERHEAD WEIGHT 8.2 lbs. WEIGHT (w/ AP 300) 12.2 lbs. GUIDE BAR LENGTH (Recommended) 14 in. OILOMATIC® CHAIN 3/8″ STIHL PICCO™ CHAIN OIL CAPACITY 7.1 oz. BATTERY SYSTEM AP System RUN TIME (w/ AP 300) UP TO 50 min. VOLTAGE 36 volt Note: STIHL recommends 61 PS3 STIHL PICCO™ Super 3699-005-0055 saw chain and 14″ 3005-000-4413 guide bar combination. Compatible guide bar ranges: 10″ to 18″. The battery working time specifications for each battery charge are estimates and may vary depending on how the tool is used and what is being cut. -
Warnings and SafetyIMPORTANT SAFETY INFORMATION The occurrence called “kickback” can cause serious or fatal injury. Always read the instruction manual carefully before using your saw. STIHL uses a green and yellow color-coding system to help you select a powerhead, bar and chain combination that complies with the kickback requirements of ANSI Standard B175.1 (gasoline-powered saws) and §30 of UL 1662/ ANSI Standard B175.1 (electric chainsaws). Ask your STIHL dealer about safe operating procedures and the advantages of the STIHL Quickstop® chain brake, STIHL Quickstop® Plus additional chain braking feature, STIHL reduced kickback bars and STIHL low-kickback saw chains.
STIHL recommends the use of green reduced kickback bars and green low kickback chains on all STIHL chainsaws.
* The actual listed guide bar length can vary from the effective cutting length based on which powerhead it is installed on.WARNING FOR CORDED ELECTRIC AND BATTERY CHAINSAW USERS! The fibers may not stop the sprocket on most corded electric chainsaws and some battery-powered chainsaws because of the constant high torque. However, to reduce the severity of injury from accidental contact with the chain, STIHL recommends that leg protection be worn when operating these types of chainsaws.WARNING FOR ELECTRIC CHAINSAW USERS!
The fibers will not stop the sprocket on most electric chainsaws because of their constant high torque.WARNING! Improper use of any power tool may cause serious or fatal injury. Read, understand, and follow carefully the operating and safety instructions in your instruction manual before using such products.
Description
Additional information
Size |
10" bar w/o battery & charger ,12" bar w/o battery & charger ,14" bar w/o battery & charger ,14" bar w/ AP 500 S battery & AL 500 charger |
---|
