Features
- Reduced-Emission Engine Technology—Caring for Nature –

  The STIHL Inc. “Caring for Nature” seal identifies its powered products that are more environmentally conscious, producing zero or low exhaust emissions. STIHL Inc. defines “low exhaust emissions” as being cleaner than EPA and/or CARB exhaust emission standards.
- STIHL ElastoStart™ –

  The ElastoStart™ starter handle is an exclusive feature of STIHL. It is a starting grip with a built-in shock absorber that helps reduce the effort when pulling on the starter cord. The ElastoStart™ starter grip noticeably reduces the sudden peak forces (compression) normally felt during cranking. The forces which occur at the grip after the first compression stroke are smoothed out.
- Fuel and oil caps with retainers –

  The fuel and oil cap retainers keep the caps attached to the unit for added convenience.
- Side-Access Chain Tensioner –

  The side-access chain tensioner makes it much more convenient for the user to adjust the saw chain with a bar wrench as opposed to the typical location of the guide bar adjustment screw.
- Adjustable Automatic Oiler –

  The Adjustable Automatic Oiler allows the user to adjust the lubricant of the guide bar and saw chain for different bar lengths and cutting conditions.
- Anti-Vibration System –

  STIHL has developed a system for minimizing the vibration levels of handheld outdoor power equipment. The STIHL anti-vibration system helps reduce operator fatigue and provides a more comfortable working experience.
- Decompression Valve –

  The decompression valve reduces the compression in the combustion chamber during cranking and helps reduce the effort needed to pull the starter rope.
- Wrap Handle (R) –

  Saw can be used in multiple positions for felling or limbing with hands in the proper positions.
- HD2 Air Filter –

  The HD2 air filter on this unit is washable, providing extremely long filter life and lowering maintenance costs. The large surface area allows for longer run times between cleanings and high performance even while operating in dusty and dry conditions. Overall, the HD2 air filter provides better protection of the engine compared to standard air filters.

Specifications

POWER SOURCE	Gas
POWERHEAD WEIGHT	16.8 lbs.
GUIDE BAR LENGTH (Recommended)	25 in.
OILOMATIC® CHAIN	3/8″ RS3
CHAIN OIL CAPACITY	13.5 oz.
ENGINE POWER	7.2 bhp
FUEL CAPACITY	28.7 oz.
DISPLACEMENT	91.1 cc

Note: STIHL recommends #3624 (33 RS3 84) OILOMATIC® saw chain and 25″ 3003 000 4030 Ematic™ guide bar combination. Compatible guide bar ranges: 16″ to 36″

Warnings and Safety

* The actual listed guide bar length can vary from the effective cutting length based on which powerhead it is installed on.

IMPORTANT SAFETY INFORMATION The occurrence called “kickback” can cause serious or fatal injury. Always read the instruction manual carefully before using your saw. STIHL uses a green and yellow color-coding system to help you select a powerhead, bar and chain combination that complies with the kickback requirements of ANSI Standard B175.1 (gasoline-powered saws) and §30 of UL 1662/ ANSI Standard B175.1 (electric chainsaws). Ask your STIHL dealer about safe operating procedures and the advantages of the STIHL Quickstop® chain brake, STIHL Quickstop® Plus additional chain braking feature, STIHL reduced kickback bars and STIHL low-kickback saw chains.

STIHL recommends the use of green reduced kickback bars and green low kickback chains on all STIHL chainsaws.

WARNING! Improper use of any power tool may cause serious or fatal injury. Read, understand, and follow carefully the operating and safety instructions in your instruction manual before using such products.
